型号 Series Model | 步距角 Step Agel | 机身长 Motor Length(mm) | 静力矩 Holding Torque(Kg.cm) | 引线数 Lead Wire | 相电流 Rated Current (A) | 相电阻 Phase Resistance | 相电感 Phase Inductance (MH) | 转动惯量Rotor Inertia(g.cm^2) | 定位力矩Detent Torque (g.cm) | 重量 Motor Weigt (kg) |
35BYG450A | 1.8 | 20 | 0.43 | 6 | 0.4 | 25 | 7 | 8 | 60 | 0.1 |
35BYG450A-01 | 1.8 | 20 | 0.43 | 5 | 0.4 | 25 | 7 | 8 | 60 | 0.1 |
35BYG250B-01 | 1.8 | 25 | 0.7 | 4 | 0.28 | 26 | 27 | 9.5 | 60 | 0.13 |
35BYG450B | 1.8 | 25 | 0.46 | 5 | 0.2 | 22 | 8 | 9.5 | 60 | 0.13 |
35BYG450C | 1.8 | 28 | 0.5 | 6 | 0.4 | 28 | 10 | 11 | 80 | 0.14 |
35BYG450C-02 | 1.8 | 28 | 0.6 | 6 | 0.2 | 39 | 16.2 | 11 | 80 | 0.14 |
35BYG450D | 1.8 | 34 | 1 | 6 | 0.4 | 21 | 10.5 | 14 | 95 | 0.17 |
35BYG450F | 1.8 | 45 | 1.7 | 6 | 0.8 | 4.2 | 4.2 | 19 | 130 | 0.23 |
