型号 Series Model | 步距角 Step Agel | 机身长 Motor Length(mm) | 静力矩 Holding Torque(Kg.cm) | 引线数 Lead Wire | 相电流 Rated Current (A) | 相电阻 Phase Resistance | 相电感 Phase Inductance (MH) | 转动惯量Rotor Inertia(g.cm^2) | 定位力矩Detent Torque (g.cm) | 重量 Motor Weigt (kg) |
42BYGH2100A | 0.9 | 26 | 1.2 | 4 | 0.8 | 7.9 | 7.5 | 21 | 140 | 0.17 |
42BYGH2100A-02 | 0.9 | 26 | 1.1 | 4 | 0.5 | 10.3 | 11.5 | 21 | 140 | 0.17 |
42BYGH2100A1A | 0.9 | 30 | 2.9 | 4 | 0.8 | 14.6 | 22.1 | 26 | 160 | 0.19 |
42BYGH2100B | 0.9 | 34.1 | 1.4 | 4 | 1 | 4.7 | 4.9 | 34 | 200 | 0.22 |
42BYGH2100B-01 | 0.9 | 34.1 | 2 | 4 | 1 | 7 | 9.6 | 34 | 200 | 0.22 |
42BYGH2100C | 0.9 | 40.1 | 2.9 | 4 | 1 | 4.6 | 8.7 | 54 | 220 | 0.28 |
42BYGH2100C-01A | 0.9 | 40.1 | 3.5 | 4 | 0.8 | 17.6 | 41 | 54 | 220 | 0.28 |
42BYGH4100C | 0.9 | 40.1 | 2.5 | 6 | 0.4 | 30 | 30 | 54 | 220 | 0.28 |
42BYGH2100D | 0.9 | 44 | 3.5 | 4 | 1 | 6.3 | 9.8 | 61 | 250 | 0.32 |
42BYGH250A | 1.8 | 32 | 2.4 | 4 | 1.4 | 2.2 | 2.48 | 25 | 185 | 0.19 |
42BYGH450A | 1.8 | 32 | 1.55 | 6 | 1 | 3.4 | 2.3 | 25 | 185 | 0.19 |
42BYGH250B | 1.8 | 34 | 1.2 | 4 | 0.4 | 6 | 6.5 | 34 | 200 | 0.22 |
42BYGH250B-06 | 1.8 | 34 | 2.4 | 4 | 0.8 | 5.5 | 7.17 | 34 | 200 | 0.22 |
42BYGH450B-01 | 1.8 | 34 | 1.7 | 6 | 0.28 | 44 | 30 | 34 | 200 | 0.22 |
42BYGH450B-02 | 1.8 | 34 | 2 | 6 | 0.8 | 7.2 | 4.4 | 34 | 200 | 0.22 |
42BYGH250C | 1.8 | 40 | 4 | 4 | 0.8 | 15.6 | 24.5 | 54 | 220 | 0.28 |
42BYGH250C-04 | 1.8 | 40 | 4.1 | 4 | 1.6 | 2.32 | 3.87 | 54 | 220 | 0.28 |
42BYGH250C-06 | 1.8 | 40 | 4.4 | 4 | 1 | 8.55 | 13 | 54 | 220 | 0.28 |
42BYGH250C-08 | 1.8 | 40 | 4 | 4 | 1 | 5.72 | 11.1 | 54 | 220 | 0.28 |
42BYGH450C | 1.8 | 40 | 2.8 | 6 | 0.4 | 30 | 24 | 54 | 220 | 0.28 |
42BYGH450C-04 | 1.8 | 40 | 2.9 | 6 | 1 | 6 | 4.2 | 54 | 220 | 0.28 |
42BYGH450C-08 | 1.8 | 40 | 2.8 | 6 | 0.8 | 5.4 | 4.38 | 54 | 220 | 0.28 |
42BYGH250D01 | 1.8 | 44 | 5 | 4 | 1 | 5.2 | 8.6 | 61 | 250 | 0.32 |
42BYGH250D02 | 1.8 | 44 | 4 | 4 | 0.5 | 27 | 51 | 61 | 250 | 0.32 |
42BYGH250D08 | 1.8 | 44 | 2.2 | 4 | 1.5 | 0.68 | 0.85 | 61 | 250 | 0.32 |
42BYGH250D09 | 1.8 | 44 | 4 | 4 | 1.2 | 3.5 | 4.9 | 61 | 250 | 0.32 |
42BYGH450 | 1.8 | 44 | 3.2 | 6 | 0.5 | 18.5 | 18.5 | 61 | 250 | 0.32 |
42BYGH450D-20 | 1.8 | 44 | 3.4 | 6 | 1 | 5 | 5.4 | 61 | 250 | 0.32 |
42BYGH450D-21 | 1.8 | 46.5 | 4 | 6 | 0.8 | 8.9 | 8.5 | 68 | 270 | 0.33 |
42BYGH450D-22 | 1.8 | 46.5 | 3.9 | 6 | 1 | 7 | 5.6 | 68 | 270 | 0.33 |
42BYGH250E-06 | 1.8 | 48 | 4.1 | 4 | 0.8 | 6.35 | 8.9 | 68 | 280 | 0.35 |
42BYGH250E-07 | 1.8 | 48 | 4.1 | 4 | 0.8 | 6.35 | 8.9 | 68 | 280 | 0.35 |
42BYGH450E-01 | 1.8 | 48 | 3.8 | 6 | 0.4 | 32 | 27 | 68 | 280 | 0.35 |
42BYGH450E-14 | 1.8 | 48 | 3.7 | 6 | 0.8 | 7.5 | 6.4 | 68 | 280 | 0.35 |
42BYGH450E-17 | 1.8 | 48 | 4.7 | 6 | 1.2 | 5 | 4.75 | 68 | 280 | 0.35 |
42BYGH250F | 1.8 | 60 | 5 | 4 | 0.5 | 23 | 35.7 | 102 | 370 | 0.46 |
42BYGH450F | 1.8 | 60 | 4.9 | 6 | 0.5 | 24 | 25 | 102 | 370 | 0.46 |
